Monel Wire Mesh Suppliers, Stockist In India

Request For Our Latest Prices On Monel Wire Mesh, Woven Wire Mesh, Welded Wire Mesh, Twill Weave Wire Mesh and Plain Weave Wire Mesh!

We Special metal manufactured and supply MONEL WIRE MESH. We supply the best quality of a product.

MONEL WIRE MESH INFORMATION:-
This Monel Mesh Wire combines nickel-iron-chromium alloy with titanium, copper, and molybdenum. The Wire Mesh shows the good mechanical property at cryogenic temperature to moderately high temperature. This wire is in conjunction with the molybdenum and copper element. Also, it gives outstanding resistance to reducing environments such as those containing sulfuric and phosphoric acid. It is designed to provide exceptional resistance to a lot of corrosive environments. Because of the level of molybdenum and copper enables this Monel Alloy Wire to resist reducing agents and acids. Because of chromium, the Monel Alloy gives resistance to oxidizing conditions, such as nitric acid solution, nitrates and oxidizing salt. These Monel Alloy are highly sought after due to their ability to resist oxidization and carbonization in high–temperature settings. There are so many alloys in the Incoloy family. Our Monel Alloy Square Wire offers users many benefits.

Alloy 400 Wire Mesh, Monel Industrial Wire Mesh, ASME SB164 Nickel Alloy 400 Wire Mesh, ASTM B164 Alloy K500 Wire Mesh, Alloy UNS N04400 Wire Mesh Supplier, ASTM B164 Monel K500 Wire Mesh Stockist, Monel Welded Wire Mesh, Monel Alloy Woven Wire Mesh Distributor, Monel Plain Weave Wire Mesh, Monel Wire Mesh Suppliers in Mumbai, India.

Table Of Content

What is Monel Wire Mesh

Monel Wire Mesh Specifications

ASTM B164 Monel Wire Mesh Equivalent Grades

Monel Wire Mesh Types

Monel Woven Wire Mesh

Monel Welded Wire Mesh

Monel Hexagonal Wire Mesh

Monel Fencing Wire Mesh

Monel Crimped Wire Mesh

Monel Netting Wire Mesh

Monel Wire Mesh Sizes

Chemical Composition of Monel Wire Mesh

Mechanical Properties of Monel Wire Mesh

Ready Stock of Monel Wire Mesh in India

Monel Wire Mesh Application Industries

People Also Searched for

WHY WE USED MONEL WIRE MESH?

These MONEL WIRE MESH is consist of excellent features and characteristics like high functional capability, good working strength, toughness, ductility, superior consistency and many more. Monel Wire Mesh is strong and durable material composed primarily of Copper and Nickel. As a copper-nickel alloy, it exhibits high strength and excellent corrosion resistance in a wide range of media. Also, including seawater and in acidic and alkaline environments. Monel wire mesh is drawn to specific diameter wires and certain specifications. This mesh is commonly used in high-performance applications, aerospace, chemical and hydrocarbon processing equipment. Also, it is used in valves, pumps, shafts, fittings and heat exchangers. Comparing to other alloy mesh wires, Monel Woven Wire Mesh offers superior heating quality and uses in different heat exchange devices, etc. Also, these wire is used in deaerating heaters for remove oxygen and other dissolved gases from boiler feedwater.

APPLICATION OF MONEL WIRE MESH?

It is used in industrial heat exchangers
It is used in the chemical and solvent industry
It is used in hydrocarbon processing equipment
It is used in the distillation of petroleum crude

Monel Twill Weave Wire Mesh, Monel Dutch Weave Wire Mesh Suppliers, Monel Crimped Weave Wire Mesh, Monel Alloy 2.4360 Wire Mesh, Nickel Alloy UNS N05500 Wire Mesh, Monel Three Heddled Weave Wire Mesh Trader, Alloy K500 Five Heddled Weave Wire Mesh, Monel Alloy Square Wire Mesh, Monel 400 Hexagonal Wire Mesh, Monel Netting Wire Mesh Stockholder, K500 Alloy Spring Steel Wire Mesh, Monel Wire Mesh in India.

One of the top most Suppliers and stockists of Monel 400 Wire Mesh, wholesaler of Monel Alloy 400 Woven Wire Mesh in Mumbai, Dealers of Monel Welded Wire Mesh Stockholder of Monel K500 Square Wire Mesh and Monel Fencing Wire Mesh used for industrial application.

Monel Wire Mesh Specification

Specification : ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Thickness Range : 10 mm To 100 mm Diameter in 100 mm TO 6000 mm Length
Surface Finish : Mill Finish, PTFE Coating
Length : Cut Lengths: 0.125″ to 72″

Monel Wire Mesh Equivalent Grades

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST
Monel 400	N04400	2.4360	NU-30M	NiCu30Fe	NW 4400	NA 13	МНЖМц 28-2,5-1,5
Monel K500	N05500	2.4375	–	–	–	–	–

Monel Wire Mesh Types

Monel Woven Wire Mesh

Nickel Alloy UNS N04400 Woven Wire Mesh
ASME SB164 Alloy 400 Woven Wire Mesh
Monel Woven Wire Mesh Supplier
Monel Woven Wire Mesh Stockist
400 Alloy Woven Wire Mesh Stockholder
Monel Alloy K500 Woven Wire Mesh
Monel UNS N05500 Woven Wire Mesh Exporter
Monel 2.4360 Woven Wire Mesh
Alloy 2.4375 Woven Wire Mesh

Monel Welded Wire Mesh

Monel Welded Wire Mesh Supplier
Nickel Alloy UNS N04400 Welded Wire Mesh
Monel 2.4360 Welding Wire Mesh
400 Alloy Welded Wire Mesh Stockholder
Monel Alloy K500 Welding Wire Mesh
ASME SB164 Alloy 400 Welded Wire Mesh
Monel Welding Wire Mesh Stockist
Monel UNS N05500 Welded Wire Mesh Exporter
Alloy 2.4375 Welded Wire Mesh

Monel Hexagonal Wire Mesh

Monel Alloy K500 Hexagonal Wire Mesh
Monel 2.4360 Hexagonal Wire Mesh
400 Alloy Hexagonal Wire Mesh Stockholder
Alloy 2.4375 Hexagonal Wire Mesh
ASME SB164 Alloy 400 Hexagonal Wire Mesh
Monel Welding Wire Mesh Stockist
Monel Hexagonal Wire Mesh Supplier
Nickel Alloy UNS N04400 Hexagonal Wire Mesh
Monel UNS N05500 Hexagonal Wire Mesh Exporter

Monel Fencing Wire Mesh

Alloy 2.4375 Fencing Wire Mesh
Nickel Alloy UNS N04400 Fencing Wire Mesh
Monel 2.4360 Fencing Wire Mesh
Monel Fencing Wire Mesh Supplier
ASME SB164 Alloy 400 Fencing Wire Mesh
Monel UNS N05500 Fencing Wire Mesh Exporter
Monel Welding Wire Mesh Stockist
Monel Alloy K500 Fencing Wire Mesh
400 Alloy Fencing Wire Mesh Stockholder

Monel Crimped Wire Mesh

Monel 2.4360 Crimped Wire Mesh
Alloy 2.4375 Crimped Wire Mesh
Nickel Alloy UNS N04400 Crimped Wire Mesh
Monel Crimped Wire Mesh Supplier
ASME SB164 Alloy 400 Crimped Wire Mesh
Monel UNS N05500 Crimped Wire Mesh Exporter
Monel Crimped Wire Mesh Stockist
Monel Alloy K500 Crimped Wire Mesh
400 Alloy Crimped Wire Mesh Stockholder

Monel Netting Wire Mesh

Monel Alloy K500 Netting Wire Mesh
Monel Netting Wire Mesh Stockist
Nickel Alloy UNS N04400 Netting Wire Mesh
Monel Netting Wire Mesh Supplier
Monel 2.4360 Netting Wire Mesh
Alloy 2.4375 Netting Wire Mesh
ASME SB164 Alloy 400 Netting Wire Mesh
400 Alloy Netting Wire Mesh Stockholder
Monel UNS N05500 Netting Wire Mesh Exporter

Monel Wire Mesh Sizes

Mesh	Wire Diameter		Opening (mm)
Mesh	mm	inch	Opening (mm)
2 mesh	1.80	0.071	10.90
3 mesh	1.60	0.063	6.866
4 mesh	1.20	0.047	5.15
5 mesh	0.91	0.036	4.17
6 mesh	0.711	0.028	3.522
8 mesh	0.610	0.024	2.565
10 mesh	0.508	0.020	2.032
12 mesh	0.457	0.018	1.660
14 mesh	0.417	0.016	1.397
16 mesh	0.345	0.014	1.243
18 mesh	0.315	0.012	1.096
20 mesh	0.315	0.0124	0.955
22 mesh	0.315	0.0124	0.840
24 mesh	0.315	0.0124	0.743
26 mesh	0.295	0.0116	0.682
28 mesh	0.295	0.0116	0.612
30 mesh	0.274	0.011	0.573
32 mesh	0.254	0.010	0.540
34 mesh	0.234	0.0092	0.513
36 mesh	0.234	0.0092	0.472
38 mesh	0.213	0.0084	0.455
40 mesh	0.193	0.0076	0.442
42 mesh	0.193	0.0076	0.412
44 mesh	0.173	0.0068	0.404
46 mesh	0.173	0.0068	0.379
48 mesh	0.173	0.0068	0.356
50 mesh	0.173	0.0068	0.335
60 × 50 mesh	0.193	0.0076	–
60 × 50 mesh	0.173	0.0068	–
60 mesh	0.173	0.0068	0.250
70 mesh	0.132	0.0052	0.231
80 mesh	0.122	0.0048	0.196
90 mesh	0.112	0.0044	0.170
100 mesh	0.012	0.004	0.152
120 × 108 mesh	0.091	0.0036	–
120 mesh	0.081	0.0032	0.131
140 mesh	0.061	0.0024	0.120
150 mesh	0.061	0.0024	0.108
160 mesh	0.061	0.0024	0.098
180 mesh	0.051	0.002	0.090
200 mesh	0.051	0.002	0.076
220 mesh	0.051	0.002	0.065
250 mesh	0.041	0.0016	0.061
280 mesh	0.035	0.0014	0.056
300 mesh	0.031	0.0012	0.054
320 mesh	0.031	0.0012	0.046
330 mesh	0.031	0.0012	0.042
350 mesh	0.031	0.0012	0.039
360 mesh	0.025	0.00098	0.0385
400 mesh	0.025	0.00098	0.0385

Specialized In Monel Wire Mesh Stockist In India, Excellent Quality In Monel 400 Wire Mesh Dealer In India, Get Custom Size Make Alloy K500 Wire Mesh at Lowest Price.

Chemical Composition of Monel Wire Mesh

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel 400	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min
Monel K500	0.25 max	1.5 max	0.5 max	0.010 max	27.00 – 33.00	0.5 – 2	63.00 min

Mechanical Composition of Monel Wire Mesh

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel 400	8.8 g/cm3	1350 °C (2460 °F)	Psi – 80,000 , MPa – 550	Psi – 35,000 , MPa – 240	40 %
Monel K500	8.44 g/cm3	1350 °C (2460 °F)	Psi – 160000 , MPa – 1100	Psi – 115000 , MPa – 790	20 %

Ready Stock of Monel Wire Mesh in India

Monel Alloy 400 Wire Mesh	Monel Industrial Wire Mesh
Monel Fencing Wire Mesh	Alloy UNS N04400 Wire Mesh
Monel 400 Welding Wire Mesh	Monel Woven Wire Mesh Stock
Monel Square Wire Mesh Suppliers	ASTM B164 Monel Fine Wire Mesh
Monel K500 Hexagonal Wire Mesh Supplier	Type 400 Monel Spring Steel Wire Mesh
ASTM B164 Monel Hex Wire Mesh	K500 Monel Spring Steel Wire Mesh Supplier
Monel 400 Welding Wire Mesh Suppliers	UNS N04400 Monel Netting Wire Mesh
Monel Reverse Dutch Wire Mesh	Alloy 400 Plain Weave Wire Mesh Stockists
Gr 400 Monel Twill Weave Wire Mesh Suppliers in Mumbai	Monel 2.4360 Dutch Weave Wire Mesh Exporter
Alloy K500 Three Heddled Weave Wire Mesh in India	Monel Alloy Five Heddled Weave Wire Mesh
Nickel Alloy 2.4375 Wire Mesh Exporter	Alloy 400 Reverse Twill Dutch Weave Wire Mesh
Monel Alloy Fine Wire Mesh	Monel Wire Mesh Supplier in India
Alloy K500 Double Crimped Wire Mesh Dealer	Monel 400 Woven Wire Mesh Stockist
Monel Wire Mesh Supplier in Mumbai	Alloy K500 Woven Wire Mesh Manufacturer in India
Monel 2.4375 Cross Twill Weave Wire Mesh	Monel Alloy Rectangular Wire Mesh
ASTM B164 Monel Alloy Wire Mesh at Best Price	Suppliers of 400 Monel Alloy Wires

Monel Alloy Wire Mesh Application Industries
